Storebro SB-355x5000
Support lathe
| Specification | |
|---|---|
| Stock number: | 010818 |
| Serial number: | 2007 |
| Swing over bed: | 710mm |
| Swing over crosslide: | 440mm |
| Swing in gap: | 970mm |
| Center distance: | 5000mm |
| Spindlebore: | 75mm |
| Spindlespeed: | 16-1180rpm |
| Taper in tailstock: | Mk5 |
| Longd. feed: | 0,115-3,467mm/r |
| Crosstravel: | 0,111-3,308mm/r |
| Threads metric: | 0,15-12mm |
| Threads inch: | 2-60/" |
| Motor: | 10hp |
| Weight: | |
Information
DRO
Fixt steady rests ø155mm, ø365mm, ø555mm
4-jaw chucks ø460mm, ø710mm
This info is to the best of our knowledge, but is not binding in detail. Buyers are responsible to ensure machines comply with local safety regulations.
